| Body | |
| Type / Mounting | Free standing, Wheel mounted |
| Construction | 1.6 mm CRCA steel sheet, polymer powder coated, Metal Top |
| Security & Mobility | Security lock system with one master key & easy transportation with four all-directional lockable wheels |
| Storage | Keyboard, Mouse Drawer, Side shelf for Laptop |
| Display | |
| Monitor | Built-in interactive Touch monitor |
| Monitor Tilt Mechanism | Electric Lifting |
| Screen Type | Scratch resistant, Antiglare |
| Size | 21.5" (54.61 cm) |
| Resolution | 1920 x 1080 (Full HD) |
| Aspect Ratio | 16:09 |
| Response Time | 5 ms |
| Viewing Angles | 170° (H) : 160° (V) |
| Touch | Finger and stylus |
| Annotation Software | Draw, Choose, Pens, Annotate, Erase, Color, Shape, Size, Text, Edit, Fonts, Stamp, Move, Capture |
| Controller | |
| Features | Power ON/OFF, Projector/Display ON/OFF, Volume control, External PC input, Touch pad keys |
| I/O Ports (Front Panel) | USB 3.0 x1, HDMI IN |
| LAN Connection | RJ 45 LAN Port |
| Source Selection | Toggle Between Various Sources Through Touch Panel |
| Audio | |
| Wireless Microphone System | Handheld Microphone x1, Collar Microphone x1, Wireless Receiver x1 |
| Gooseneck Microphone | 80 cm length, double soft copper tube, 1.5m wire, 3 core cannon plug |
| Amplifier & Speakers | 100W RMS Amplifier and 4 speakers of 50W RMS each |
| Visual Presenter | |
| Camera | 5 Megapixel |
| Shooting Area | A4 |
| Software | Yes |
| Focus Mode | Auto Focus, Digital Zoom |
| Light Source | Built-in high strength LED light |
| Interface | USB |
| System Details (Optional) | |
| CPU | Core i3/i5/i7 (III/IV Gen) |
| RAM | 2GB / 4GB / 8GB |
| Storage | 500GB / 1TB SATA HDD |
| Audio | Line-Out x1 / Line-In x1 |
| Wi-Fi | Built-in Wi-Fi |
| Keyboard & Mouse | Wireless Keyboard and Mouse Provided |
| Operating System | Windows 10 |
| Power | |
| Power Supply | 100-240V, 50Hz, AC |
| Power Consumption | 120 Watt (Max) |
| Environment | |
| Operating Temperature | 5°C – 45°C |
| Operating Humidity | Up to 90% RH (Non-condensing) |
| Physical Specifications | |
| Weight | 140 Kg |
| Dimensions (L x W x H) | 668 x 635 x 1150 mm |
Provide an immersive experience with 4K resolution, up to 40 points of touch, a built-in top-oriented sound bar and microphone array, and a convenient camera USB port location.
| Size: | 86″ |
| Screen Type: | LED |
| Aspect Ratio: | 16:9 |
| Display Area: | 74.61″ x 41.97″ |
| Resolution: | 3840(H) x 2160(V) Ultra HD |
| Pixel Pitch: | 0.4935 mm x 0.4935 mm |
| Back Light Unit: | Direct type LED |
| Response Time: | 6.5 ms |
| Refreshing Frequency: | 60Hz |
| Display Color: | 1.07B (10 bit) |
| Brightness: | 350 cd/m2 |
| Static Contrast Ratio: | 1200:1 |
| Dynamic Contrast Ratio: | 4000:1 |
| Viewing Angle: | 178° |
| Life Time: | ≥50,000 hours |
